OKVIR: Chrono 29 6061 Xtralite Alloy butted, XC Forward Geometry, 73mm BSA bottom bracket, tapered head tube, HHG Internal Cable Routing, Boost 12x148mm rear axle
VILICA: RockShox Judy Silver TK 29, 120mm, TurnKey, Solo Air, tapered steerer tube, 9x100mm axle, 30mm steel stanchions, 51mm offset. Settings: Poplock 2 pos remote compression (open/lock), rebound, air preload
DALJINSKO ZAKLJUČAVANJE VILICE: RockShox PopLoc
LEŽAJ VILICE: Onoff Saturn tapered for 1-1/8” to 1-1/2” head tube, ACB sealed bearings, top 41x30.2x7x45ºx45º, bottom 51.9x40x8x45ºx45º
LULICA: Onoff Sulfur, 6061 T6 Alloy, 31.8mm barbore, rise: +/-7º, length: S size: 50mm, M size: 50mm, L size: 60mm, XL size: 70mm
UPRAVLJAČ: Onoff Sulfur 0.2, double butted 6061 alloy, rise: 4.8mm, width: 740mm, 9º backsweep, 0º upsweep, 31.8mm barbore
GRIPOVI: Onoff Twin, 1lock-on, 135mm
CIJEV SJEDALA: Onoff Sulfur 0-R, 6061 T6 Alloy, 3D forged, diameter 31,6mm, length 400mm
SJEDALO: Mondraker XC Series, steel rail
PREDNJA KOČNICA: Sram Level, 2 piece caliper, Centerline 180mm IS 6 bolts one-piece rotor, steel-backed organic pad
STRAŽNJA KOČNICA: Sram Level, 2 piece caliper, Centerline 160mm IS 6 bolts one-piece rotor, steel-backed organic pad
RUČICA KOČNICE: Sram Level, tooled reach adjust, lever pivot bushings
OBRUČI: MDK-XP1 29 TLR, 25mm internal width, tubeless ready, 32 spokes
ŽBICE: CN round stainless steel
PREDNJA GLAVČINA: Formula DC20LW, 9x100mm, cup & cone ball bearings, IS 6 bolts
STRAŽNJA GLAVČINA: Formula MST148S-4SB, Boost 12x148mm, sealed bearings, IS 6 bolts, HG freehub
PREDNJA GUMA: Maxxis Ardent 29x2.40, Dual compound, EXO, tubeless ready, 60TPI, folding bead
STRAŽNJA GUMA: Maxxis Ardent 29x2.40, Dual compound, EXO, tubeless ready, 60TPI, folding bead
POGON: Sram SX Eagle, Boost, DUB axle, Direct Mount chain ring, S size: 170mm M size: 175mm L size: 175mm XL size: 175mm, CL 52
LANČANIK: 34T, steel, X-Sync 2
LEŽAJ POGONA: Sram DUB BSA, sealed bearings, 73mm
LANAC: Sram SX Eagle, 12s, Powerlock
STRAŽNJI MJENJAČ: Sram SX Eagle, Type 3 roller bearing clutch, cage lock, long cage, 1x12s, X-actuation 1:1
RUČICE MJENJAČA: Sram Trigger SX Eagle, 12s, X-Actuation 1:1
KAZETA: Sram PG-1210, 11-50T, 12s
NOSAČ MJENJAČA: Mondraker M068
TEŽINA: 13,6 kg
